88mm Stainless Steel Recessed Gate Track Wheel (GTR237)

<a href="https://www.richmondau.com/wp-content/uploads/2021/04/GTR236-GTR237-specs.jpg"><img class="alignnone wp-image-73279 size-full" src="https://www.richmondau.com/wp-content/uploads/2021/04/GTR236-GTR237-specs-e1617254352863.jpg" alt="" width="800" height="396" /></a>
A: 24mm
B: 14.5mm
C: 20.5mm
D: 88mm
D1: 70mm
E: 34mm
F: 128mm
G: 152mm
Capacity: 250kg
Wheel Material: Stainless Steel
Frame Material: Stainless Steel
<div class="combined_desc_block">Mounts recessed into the bottom of the gate for a low gate profile. C Groove profile to suit <a href="https://admerch.com.au/product/bolt-down-sliding-gate-track/">GTR010</a> gate track.</div>
<div></div>
<div class="combined_desc_block">Complete stainless steel wheel with stainless bearings and housing.  Including double stainless steel 2RS grade 440 bearings for stronger sealing protection and better rolling friction compared to a traditional mild steel outer shield. All Track Wheels are fitted with quality bearings and the double bearing design allows for an increased load capacity.</div>
<div></div>
<div class="combined_desc_block">The precision C groove ensures a smooth and consistent rolling action on the gate track. For track to suit, see <a href="https://admerch.com.au/product/bolt-down-sliding-gate-track/">GTR010</a>.</div>
